HIGH FREQUENCY RECIPROCATING TRIBOMETER

The TE 77 High Frequency Reciprocating Tribometer is a well-known and versatile friction machine and research and development tool for the evaluation of lubricants, materials, coatings, and surface treatments.

The TE 77 is capable of matching sliding contact conditions to a number of machine elements. Specimens may either be of a standard format, or can be cut from real components, preserving surface finish and other properties.

Studies onGeometriesMaterial TestingConditionsMotion

  • Additive screening
  • Tribo-corrosion
  • Fretting wear
  • Diesel fuel lubricity

  • Corrosion and wear
  • Stribeck curve
  • Friction modifier
  • Grease testing

  • Dynamic friction
  • Extreme pressure
  • Crankcase lubricants
  • ASTM Standard testing

  • Ball on disc
  • FZG test simulation
  • Sliding line contact

  • Ring and liner
  • Ball on plate

  • Ceramics
  • Piston skirt materials
  • Cam shaft materials

  • Plastics
  • Coatings
  • Seals

  • Hertzian contact
  • Boundary lubrication
  • Low and high temperature
  • Scuffing

  • Reciprocating sliding
  • Impact sliding
  • Sliding-rolling contact
  • Stick-slip

ROTARY TRIBOMETER

The TE 92 Rotary Tribometer is a highly versatile rig for research and development on materials and lubricants. The machine is available in a number of different configurations to meet different testing requirements.

Studies onGeometriesMaterial TestingConditionsMotion

  • Additive screening
  • Extreme pressure
  • Shear Stability Test
  • VI improvers

  • Corrosion and wear
  • Rolling Contact Fatigue
  • Thrust washer

  • Block on ring
  • Pin on vee block
  • Rolling element bearing
  • Taper roller bearing

  • Journal bearing Ring and liner
  • Pin on disc
  • Rolling four ball
  • Vane pump

  • Cylinder liner materials
  • Clutch lubricants
  • Plain bearing materials
  • Rolling bearing materials

  • Friction materials
  • Clutch materials
  • Piston ring materials
  • Self-lubrication materials

  • Starving lubrication
  • Boundary lubrication
  • Low and high temperature

  • Rolling contact
  • Rolling/Sliding
  • Engine simulation
  • Bearing simulation

  • Sliding four ball
  • Gear simulation

TWO ROLLER TRIBOMETER

The TE 74 and 73 and 72 Two Roller Machine is a research rig for the study of wear and rolling contact fatigue of materials under conditions of pure rolling, rolling, and sliding. The machine incorporates two motors, one to provide the input power and one to absorb the transmitted power.

Studies onGeometriesMaterial TestingConditionsMotion

  • Gear lubricants
  • Pitting, Micropitting, scuffing, WEC
  • Traction coefficient
  • Traction fluids

  • Gear materials Gear surface treatments
  • Rail friction
  • Traction curve
  • Rolling mill

  • Rolling contact
  • Elliptical contact
  • Rail-wheel interface
  • Sliding-rolling line contact

  • Block on ring

  • Cam shaft materials
  • Hypoid gear lubricants

  • Elastohydrodynamic
  • Starving lubrication
  • High temperature
  • High number of cycles

  • Hertzian contact
  • Dry lubrication

  • Sliding-rolling contact
  • Pure rolling
  • Contact spin
  • Gear simulation

  • Pure sliding

DAIMLER RRV ROTARY RING LINE TRIBOMETER

The Daimler RRV Rotary Ring Line Tribometer test configuration allows multiple ring samples running against an unmodified cylinder liner for engine simulation. The key difference between this device and more conventional reciprocating ring-liner test is that instead of running up and down the liner, the samples are run around the internal circumference of the liner in either continuous rotation with high sliding speeds, or oscillating motion.

Studies onGeometriesMaterial TestingConditionsMotion

  • Power Piston Design
  • Oil/Fuel influence on ring/liner wear
  • Cylinder Scuffing
  • Lubricant film thickness

  • Bore polish
  • Corrosion and wear
  • VI improvers
  • Ring-liner mid-stroke speed studies

  • Engine oil additive interaction with surface

  • Multi-station
  • Ring and liner
  • Fired engine simulation

  • Piston ring materials
  • Antifriction materials
  • Coated cylinder materials
  • Self-lubricating coatings

  • Cylinder liner materials
  • PTWA coatings
  • Piston ring materials

  • Starving lubrication
  • Boundary lubrication
  • Low and high temperature
  • Mid-stroke speeds

  • Ring Sliding contact
  • Rotary
  • Reciprocating
  • Ring-Reversal motion

  • Engine simulation

FUEL LUBRICITY WEAR

The TE 80 Two Station Fuel Lubricity Wear Test Machine incorporates two test stations with heater pads and mounting arrangements for ISO 12156 and ASTM D6079 fuel lubricity test specimens.

If you have the need for any other tribological test or have any questions about these machines please contact us.

Studies onMotion

  • Diesel fuel lubricity
  • Fuel lubricity

  • Reciprocating sliding
